Embassy Book

git clone https://github.com/embassy-rs/embassy.git
cd embassy

cd examples/nrf52840
cargo build --bin blinky --release

cargo run --bin blinky --release

    Finished dev [unoptimized + debuginfo] target(s) in 1m 56s
     Running `probe-rs run --chip STM32F407VGTx target/thumbv7em-none-eabi/debug/blinky`
(HOST) INFO  flashing program (71.36 KiB)
(HOST) INFO  success!
────────────────────────────────────────────────────────────────────────────────
0 INFO  Hello World!
└─ blinky::__embassy_main::task::{generator#0} @ src/bin/blinky.rs:18
1 INFO  high
└─ blinky::__embassy_main::task::{generator#0} @ src/bin/blinky.rs:23
2 INFO  low
└─ blinky::__embassy_main::task::{generator#0} @ src/bin/blinky.rs:27
3 INFO  high
└─ blinky::__embassy_main::task::{generator#0} @ src/bin/blinky.rs:23
4 INFO  low
└─ blinky::__embassy_main::task::{generator#0} @ src/bin/blinky.rs:27

embassy-executor = { version = "0.10.0", path = "../../../embassy-executor", features = ["defmt", "platform-cortex-m", "executor-thread"] }
embassy-time = { version = "0.5.1", path = "../../../embassy-time", features = ["defmt"] }
embassy-nrf = { version = "0.10.0", path = "../../../embassy-nrf", features = ["defmt", "nrf52840", "time-driver-rtc1", "gpiote"] }

cargo new stm32g474-example
cd stm32g474-example

stm32g474-example
├── Cargo.toml
└── src
    └── main.rs

fn process_buffer(mut buf: [u8; 1024]) -> [u8; 1024] {
    // 処理を行い、新しいバッファを返す
    for elem in buf.iter_mut() {
        *elem = 0;
    }
    buf
}

pub fn main() -> () {
    let buf = [1u8; 1024];
    let buf_new = process_buffer(buf);
    // buf_new に対して何らかの処理を行う
    ()
}

fn process_buffer<'a>(buf: &'a mut [u8]) -> &'a mut[u8] {
    for elem in buf.iter_mut() {
        *elem = 0;
    }
    buf
}

pub fn main() -> () {
    let mut buf = [1u8; 1024];
    let buf_new = process_buffer(&mut buf);
    // buf_new に対して何らかの処理を行う
    ()
}

#![no_std]
#![no_main]

use pac::gpio::vals;
use {defmt_rtt as _, panic_probe as _, stm32_metapac as pac};

#[cortex_m_rt::entry]
fn main() -> ! {
    // Enable GPIO clock
    let rcc = pac::RCC;
    rcc.ahb2enr().modify(|w| {
        w.set_gpioben(true);
        w.set_gpiocen(true);
    });

    rcc.ahb2rstr().modify(|w| {
        w.set_gpiobrst(true);
        w.set_gpiocrst(true);
        w.set_gpiobrst(false);
        w.set_gpiocrst(false);
    });

    // Setup button
    let gpioc = pac::GPIOC;
    const BUTTON_PIN: usize = 13;
    gpioc.pupdr().modify(|w| w.set_pupdr(BUTTON_PIN, vals::Pupdr::PullUp));
    gpioc.otyper().modify(|w| w.set_ot(BUTTON_PIN, vals::Ot::PushPull));
    gpioc.moder().modify(|w| w.set_moder(BUTTON_PIN, vals::Moder::Input));

    // Setup LED
    let gpiob = pac::GPIOB;
    const LED_PIN: usize = 14;
    gpiob.pupdr().modify(|w| w.set_pupdr(LED_PIN, vals::Pupdr::Floating));
    gpiob.otyper().modify(|w| w.set_ot(LED_PIN, vals::Ot::PushPull));
    gpiob.moder().modify(|w| w.set_moder(LED_PIN, vals::Moder::Output));

    // Main loop
    loop {
        if gpioc.idr().read().idr(BUTTON_PIN) == vals::Idr::Low {
            gpiob.bsrr().write(|w| w.set_bs(LED_PIN, true));
        } else {
            gpiob.bsrr().write(|w| w.set_br(LED_PIN, true));
        }
    }
}

#![no_std]
#![no_main]

use cortex_m_rt::entry;
use embassy_stm32::gpio::{Input, Level, Output, Pull, Speed};
use {defmt_rtt as _, panic_probe as _};

#[entry]
fn main() -> ! {
    let p = embassy_stm32::init(Default::default());
    let mut led = Output::new(p.PB14, Level::High, Speed::VeryHigh);
    let button = Input::new(p.PC13, Pull::Up);

    loop {
        if button.is_low() {
            led.set_high();
        } else {
            led.set_low();
        }
    }
}

#![no_std]
#![no_main]

use core::cell::RefCell;

use cortex_m::interrupt::Mutex;
use cortex_m::peripheral::NVIC;
use cortex_m_rt::entry;
use embassy_stm32::gpio::{Input, Level, Output, Pull, Speed};
use embassy_stm32::{interrupt, pac};
use {defmt_rtt as _, panic_probe as _};

static BUTTON: Mutex<RefCell<Option<Input<'static>>>> = Mutex::new(RefCell::new(None));
static LED: Mutex<RefCell<Option<Output<'static>>>> = Mutex::new(RefCell::new(None));

#[entry]
fn main() -> ! {
    let p = embassy_stm32::init(Default::default());
    let led = Output::new(p.PB14, Level::Low, Speed::Low);
    let mut button = Input::new(p.PC13, Pull::Up);

    cortex_m::interrupt::free(|cs| {
        enable_interrupt(&mut button);

        LED.borrow(cs).borrow_mut().replace(led);
        BUTTON.borrow(cs).borrow_mut().replace(button);

        unsafe { NVIC::unmask(pac::Interrupt::EXTI15_10) };
    });

    loop {
        cortex_m::asm::wfe();
    }
}

#[interrupt]
fn EXTI15_10() {
    cortex_m::interrupt::free(|cs| {
        let mut button = BUTTON.borrow(cs).borrow_mut();
        let button = button.as_mut().unwrap();

        let mut led = LED.borrow(cs).borrow_mut();
        let led = led.as_mut().unwrap();
        if check_interrupt(button) {
            if button.is_low() {
                led.set_high();
            } else {
                led.set_low();
            }
        }
        clear_interrupt(button);
    });
}
//
//
//
//

#![no_std]
#![no_main]

use embassy_executor::Spawner;
use embassy_stm32::exti::{self, ExtiInput};
use embassy_stm32::gpio::{Level, Output, Pull, Speed};
use embassy_stm32::{bind_interrupts, interrupt};
use {defmt_rtt as _, panic_probe as _};

bind_interrupts!(
    pub struct Irqs{
        EXTI15_10  => exti::InterruptHandler<interrupt::typelevel::EXTI15_10 >;
});

#[embassy_executor::main]
async fn main(_spawner: Spawner) {
    let p = embassy_stm32::init(Default::default());
    let mut led = Output::new(p.PB14, Level::Low, Speed::VeryHigh);
    let mut button = ExtiInput::new(p.PC13, p.EXTI13, Pull::Up, Irqs);

    loop {
        button.wait_for_any_edge().await;
        if button.is_low() {
            led.set_high();
        } else {
            led.set_low();
        }
    }
}

    <IP InstanceName="I2C1" Name="I2C" Version="i2c2_v1_1_Cube"/>
    <!-- 中略  -->
    <IP ConfigFile="TIM-STM32F0xx" InstanceName="TIM1" Name="TIM1_8F0" Version="gptimer2_v2_x_Cube"/>

    (".*:I2C:i2c2_v1_1", ("i2c", "v2", "I2C")),
    // 中略
    (r".*TIM\d.*:gptimer.*", ("timer", "v1", "TIM_GP16")),

    {
        "name": "I2C1",
        "address": 1073763328,
        "registers": {
            "kind": "i2c",
            "version": "v2",
            "block": "I2C"
        },
        // 中略
    }
    // 中略
    {
        "name": "TIM1",
        "address": 1073818624,
        "registers": {
            "kind": "timer",
            "version": "v1",
            "block": "TIM_ADV"
        },
        // 中略
    }

#[cfg(i2c)]
pub mod i2c;

#[cfg_attr(i2c_v2, path = "v2.rs")]

use embassy_executor::task;
use embassy_time::{Duration, Timer};

#[task]
/// 定期的にティックするタスク
async fn tick_periodic() -> ! {
    loop {
        rprintln!("tick!");
        // 非同期スリーププリミティブ。タスクを 500ms の間停止します。
        Timer::after(Duration::from_millis(500)).await;
    }
}

use embassy_executor::task;
use embassy_time::Delay;

#[task]
/// 定期的にティックするタスク
async fn tick_periodic() -> ! {
    loop {
        rprintln!("tick!");
        // 非同期スリーププリミティブ。タスクを 500ms の間停止します。
        generic_delay(Delay).await
    }
}

async fn generic_delay<D: embedded_hal_async::delay::DelayNs>(delay: D) {
      delay.delay_ms(500).await;
}

use defmt::*;
use embassy_executor::Spawner;
use embassy_rp::gpio;
use embassy_sync::blocking_mutex::raw::ThreadModeRawMutex;
use embassy_sync::mutex::Mutex;
use embassy_time::{Duration, Ticker};
use gpio::{AnyPin, Level, Output};
use {defmt_rtt as _, panic_probe as _};

type LedType = Mutex<ThreadModeRawMutex, Option<Output<'static, AnyPin>>>;
static LED: LedType = Mutex::new(None);

#[embassy_executor::main]
async fn main(spawner: Spawner) {
    let p = embassy_rp::init(Default::default());
    // グローバルな LED 参照の内容を実際の LED ピンに設定する
    let led = Output::new(AnyPin::from(p.PIN_25), Level::High);
    // ミューテックスに書き込まれると MutexGuard がドロップされ、それによって
    // Mutex が解放されるように、内側のスコープを使っている
    {
        *(LED.lock().await) = Some(led);
    }
    let dt = 100 * 1_000_000;
    let k = 1.003;

    unwrap!(spawner.spawn(toggle_led(&LED, Duration::from_nanos(dt))));
    unwrap!(spawner.spawn(toggle_led(&LED, Duration::from_nanos((dt as f64 * k) as u64))));
}

// プールサイズが 2 であることは、このタスクのインスタンスを 2 つ spawn できることを意味する。
#[embassy_executor::task(pool_size = 2)]
async fn toggle_led(led: &'static LedType, delay: Duration) {
    let mut ticker = Ticker::every(delay);
    loop {
        {
            let mut led_unlocked = led.lock().await;
            if let Some(pin_ref) = led_unlocked.as_mut() {
                pin_ref.toggle();
            }
        }
        ticker.next().await;
    }
}

use defmt::*;
use embassy_executor::Spawner;
use embassy_rp::gpio;
use embassy_sync::blocking_mutex::raw::ThreadModeRawMutex;
use embassy_sync::channel::{Channel, Sender};
use embassy_time::{Duration, Ticker};
use gpio::{AnyPin, Level, Output};
use {defmt_rtt as _, panic_probe as _};

enum LedState {
     Toggle,
}
static CHANNEL: Channel<ThreadModeRawMutex, LedState, 64> = Channel::new();

#[embassy_executor::main]
async fn main(spawner: Spawner) {
    let p = embassy_rp::init(Default::default());
    let mut led = Output::new(AnyPin::from(p.PIN_25), Level::High);

    let dt = 100 * 1_000_000;
    let k = 1.003;

    unwrap!(spawner.spawn(toggle_led(CHANNEL.sender(), Duration::from_nanos(dt))));
    unwrap!(spawner.spawn(toggle_led(CHANNEL.sender(), Duration::from_nanos((dt as f64 * k) as u64))));

    loop {
        match CHANNEL.receive().await {
            LedState::Toggle => led.toggle(),
        }
    }
}

// プールサイズが 2 であることは、このタスクのインスタンスを 2 つ spawn できることを意味する。
#[embassy_executor::task(pool_size = 2)]
async fn toggle_led(control: Sender<'static, ThreadModeRawMutex, LedState, 64>, delay: Duration) {
    let mut ticker = Ticker::every(delay);
    loop {
        control.send(LedState::Toggle).await;
        ticker.next().await;
    }
}

[unstable]
build-std = ["core"]
build-std-features = ["panic_immediate_abort"]

#[exception]
unsafe fn HardFault(_frame: &ExceptionFrame) -> ! {
    SCB::sys_reset() // <- reset 以外のこともできます
}

DMA: error on BDMA@1234ABCD channel 4

[patch.crates-io]
# GitHub から最新の git rev を取得するようにしてください。最新のものはここで確認できます:
# https://github.com/embassy-rs/embassy/commits/main/
embassy-embedded-hal = { git = "https://github.com/embassy-rs/embassy",     rev = "4cade64ebd34bf93458f17cfe85c5f710d0ff13c" }
embassy-executor     = { git = "https://github.com/embassy-rs/embassy",     rev = "4cade64ebd34bf93458f17cfe85c5f710d0ff13c" }
embassy-rp           = { git = "https://github.com/embassy-rs/embassy",     rev = "4cade64ebd34bf93458f17cfe85c5f710d0ff13c" }
embassy-sync         = { git = "https://github.com/embassy-rs/embassy",     rev = "4cade64ebd34bf93458f17cfe85c5f710d0ff13c" }
embassy-time         = { git = "https://github.com/embassy-rs/embassy",     rev = "4cade64ebd34bf93458f17cfe85c5f710d0ff13c" }
embassy-usb          = { git = "https://github.com/embassy-rs/embassy",     rev = "4cade64ebd34bf93458f17cfe85c5f710d0ff13c" }
embassy-usb-driver   = { git = "https://github.com/embassy-rs/embassy",     rev = "4cade64ebd34bf93458f17cfe85c5f710d0ff13c" }

const {
    core::assert!(Self::PAGE_SIZE % ACTIVE::WRITE_SIZE as u32 == 0);
    core::assert!(Self::PAGE_SIZE % ACTIVE::ERASE_SIZE as u32 == 0);
    core::assert!(Self::PAGE_SIZE % DFU::WRITE_SIZE as u32 == 0);
    core::assert!(Self::PAGE_SIZE % DFU::ERASE_SIZE as u32 == 0);
}

// コピーの進捗を保存するために十分な進捗ページを確保する
assert_eq!(0, Self::PAGE_SIZE % aligned_buf.len() as u32);
assert!(aligned_buf.len() >= STATE::WRITE_SIZE);
assert_eq!(0, aligned_buf.len() % ACTIVE::WRITE_SIZE);
assert_eq!(0, aligned_buf.len() % DFU::WRITE_SIZE);

#[panic_handler]
fn panic(_info: &core::panic::PanicInfo) -> ! {
    for _ in 0..10_000_000 {
        cortex_m::asm::nop();
    }
    cortex_m::asm::udf();
}
